Introduction
Steyr 4×2 cargo truck is suitable for medium and short transportation of cargos and goods. Steyr cargo truck is well known for strong power, low oil consumption, stable performance and multiple personalized configurations. This heavy truck cab owns luxurious, elegant, beautiful, safe and comfortable properties. The truck is usually composed of four parts including the engine, chassis, body and electrical equipment. Shaanxi Automobile Group is a leading exporter of Steyr 4×2 cargo trucks in China. We have many years of Steyr cargo truck production experience. Our products also cover dump truck, tractor truck, garbage truck, powder truck, crane truck, water truck, oil tank truck, concrete mixer truck, and so on. Our heavy trucks are sold to more than 80 countries including Eastern Europe and CIS countries, Africa, Southeast Asia, Central and South America, Middle East, etc.
Technical Parameters of STEYR 4×2 Cargo Truck
Max. Speed (km/h) | 92 | ||
Drive System | 4 × 2 | ||
Dimensions (L × W × H) (mm) | Overall | 8500 × 2495 × 3210 | |
Tipper Body | 6000 × 2326 × 600, 800 | ||
Thickness (mm) | floor: 3, side: 2, or at buyer’s option | ||
Curb Weight (kg) | 7975 | ||
Total Mass (kg) | 16000 | ||
Wheel Base (mm) | 4600 | ||
Wheel Track (mm) (F/R) | 1939 / 1800 | ||
Overhang (mm) (F/R) | 1525 / 2375 | ||
Approach / Departure Angle (°) | 18 / 13 | ||
Engine | WD615.56 / WP10.290E32 ( WEICHAI) | ||
Horsepower | 260 / 290 HP | ||
Gearbox | 8JS118 / 9JS119 (FAST GEAR) | ||
Clutch | Ф 430 Diaphragm type | ||
Steering Engine | ZF technology | ||
Cab | Standard STEYR cabin with A/C | ||
Axle | Front | 6.5 tons | |
Rear | 13 Ton STR hub reduction axle, final ratio: 4.8 | ||
Tire | 11.00R20 / 12.00R20 | ||
Fuel Tank (L) | 380 |
