STEYR 6×4 Dump Truck

Introduction
STEYR 6×4 dump truck adopts mature technology and its chassis is higher than Delong series. STEYR tipper truck is quite suitable for short and medium distance transportation. STEYR series dumpers possess reliable structure, strong load capacity, strong power, stable performance and higher market awareness. It can adapt to harsh environments of construction site and mining area. STEYR 6×4 dump truck is typically applicable in short-haul mining earthwork construction and engineering construction. STEYR tipper truck consists of cab, engine, transmission, front axle, rear axle, tire and other spare parts. Due to the good performance of each component, our dump trucks can meet customers’ specific transportation requirements.

Characteristics

1. STEYR 6×4 dump truck has highly efficient, comfortable and humanized space. The interior trimmings and configurations are arranged perfectly. STEYR tipper truck’s elegant and delighted driving environment is built on the international advanced comfortable and human-oriented design.
2. This heavy truck adopts advanced technology. It embodies a series of efforts of our new development. With high efficient and oil-saving strong driving force, STEYR 6×4 dump truck is simple and comfortable to operate.
3. STEYR tipper truck is equipped with a special vehicle suspension system.

Technical Specifications

Model			SX3254BM294	SX3254BS384
Max. Speed (km/h)			77	77
Drive System			6 × 4	6 × 4
Dimensions (L × W × H) (mm)		Overall	7550 × 2490 × 3450	8400 × 2490 × 3450
		Tipper Body	4800 × 2388 × 1500	5600 × 2300 × 1500
Thickness (mm)			floor: 8, side: 6, or at buyer’s option
Hydraulic Lifting System			Middle lifting or HYVA front lifting
Curb Weight (kg)			12200	12200
Total Mass (kg)			25000	25000
Wheel Base (mm)			2925 plus 1350	3800 plus 1350
Wheel Track (mm) (F/R)			1939 / 1800	1939 / 1800
Overhang (mm) (F/R)			1576 / 1529	1576 / 1600
Approach / Departure Angle (°)			28 / 31
Engine			WD615.50 / WD12.336 ( WEICHAI, Euro II)
Horsepower			290 / 336 HP
Gearbox			RTD-11509C (FAST GEAR)
Clutch			Ф 430 diaphragm type
Steering Engine			ZF technology
Cab			Standard STEYR cabin with A/C
Axle	Front		8 tons
	Rear		2*13 ton hub reduction axle, final ratio: 5.73
Tire			11.00R20 / 12.00R20 (10+1)
Fuel Tank (L)			200 / 380

Shaanxi Automobile Group is a leading exporter of STEYR 6×4 dump trucks in China. We have many years of STEYR tipper truck production experience. Our products also cover off-road vehicles, medium-duty trucks, large and medium-sized coaches, medium and light-duty trucks, minivan, new energy vehicles, heavy-duty axles, light axles, Cummins engines, automobile parts, etc. Our dumpers are sold to more than 80 countries including Eastern Europe and CIS countries, Africa, Southeast Asia, Central and South America, Middle East, and so forth.
