F3000 6×4 Tractor Truck

F3000 6×4 Tractor Truck

Introduction
F3000 6×4 tractor truck is one of our hot selling products. The trailer head truck adopts advanced key assemblies and it is reasonably connected by advanced technology. This truck tractor head possesses outstanding performances on power, economical efficiency, reliability and environmental protection. It owns the advantages of reliable structure, strong load capability, superior power and stable performance. Its cab is beautiful, elegant, safe and comfortable. This trailer head truck is quite suitable for highway long-distance transportation and high-speed highway transportation. Adopting multiple power oil-saving switch for different loading situation, F3000 6×4 truck tractor head can reduce customers’ cost to the minimum. In order to meet different needs of customers’ different transport medium, Shacman tractor trucks can be divided into light weight version and strengthening version. Clients can choose the suitable trailer head truck according to specific transportation requirements.

Technical Parameters of F3000 6×4 Tractor Truck

Model SX4255NT324 SX4257NX324
Max. Speed (km/h) 99 99
Drive System 6 × 4 6 × 4
Dimension  (L × W × H) (mm) 6825 × 2490 × 3624, 3204, 3851, 4000
Curb Weight (kg) 8870 9400
Total Mass (kg) 25000 25000
Wheel Base  (mm) 3175 plus 1350
Wheel Track (mm)  (F/R)   2036 / 1800, 1860
Overhang (mm)  (F/R) 1525 / 725
Approach / Departure Angle (°) 20 / 66
Engine WD10.336 / WD10.375 (Weichai, Euro 2) WP10.375 / ISME385 30WP12.430 / WP12.460 (WEICHAI or CUMMINS)
Horsepower 375 / 385 / 430 / 460 HP
Gearbox RTD-11509C / 12JSD160T / 12JSD200T (FAST GEAR)
Clutch Ф 430 diaphragm type
Steering  Engine ZF technology
Cab MAN F3000 flat / high roof cabin with A/C and sleeper
Axle Front 7.5 tons
Rear 2 * 13 / 16 ton driving axle, final ratio: 4.111
Tire 12.00R20 / 12R22.5 (10+1)
Fifth Wheel 90
Fuel Tank (L) 400

Shaanxi Automobile Group is engaged in providing F3000 6×4 tractor trucks in China. We have over 40-year production experience of trailer head trucks. In addition to this truck tractor head, our products also cover off-road vehicles, medium-duty trucks, large and medium-sized coaches, medium and light-duty trucks, minivan, new energy vehicles, heavy-duty axles, light axles, Cummins engines, automobile parts, etc. SHACMAN heavy duty trucks are sold to more than 80 countries including Eastern Europe and CIS countries, Africa, Southeast Asia, Central and South America, Middle East, and so forth.
