F3000 6×4 Dump Truck

Introduction
F3000 6×4 dump truck is a kind of heavy duty truck or commercial truck. This self-discharging truck is of high cost performance. It is equipped with an advanced platform, chassis system, high quality stander and other parts. This dump truck has 6 to 12 gears for transmission. The power of its engine takes WP10.340E32/WP10.336/ ISME345 30, so this F3000 6×4 dump truck can meet customers’ different transportation requirements. F3000 6×4 self-discharging truck is mainly used to transport sand, gravel or dirt in construction area.

Features

1. Different trucks used for city construction and mine area have different functions to satisfy clients’ different requirements.
2. Shacman F3000 6×4 dump truck is more comfortable with 4-point air suspension driver seat and electrical window regulator.
3. Our self-discharging truck features high reliability and high load capacity. It is typically used for short and medium distance transportation of earth, core and mine. It is also applied in water-power engineering construction.
4. Shanqi F3000 6×4 dump truck is one of our top selling products. It owns stable structure, strong carrying capability and reliable performance. With high market awareness, our self-discharging trucks are even suitable for harsh construction environment.

Technical Parameters

Model			SX3255DR354	SX3255DR384
Max. Speed (km/h)			85	85
Drive System			6 × 4	6 × 4
Dimensions (L × W × H) (mm)		Overall	8130 × 2490 × 3450	8550 × 2490 × 3450
		Tipper Body	5200 / 5400 × 2300 × 1500	5600 / 5800 × 2300 × 1500
Thickness (mm)			floor: 8, side: 6, or at buyer’s option
Hydraulic Lifting System			Middle lifting	HYVA front lifting
Curb Weight (kg)			12100	12500
Total Mass (kg)			25000	25000
Wheel Base (mm)			3525 plus 1350	3800 plus 1350
Wheel Track (mm) (F/R)			2036, 2018 / 1850	2036, 2018 / 1850
Overhang (mm) (F/R)			1525 / 1654	1525 / 1654
Approach / Departure Angle (°)			28 / 30	28 / 30
Engine			WP10.340E32/WP10.336 / ISME345 30 (Weichai/Cummins)
Horsepower			340 / 336 / 345 HP
Gearbox			10JSD140 / 10JSD160 / 12JSD160T (FAST GEAR)
Clutch			Ф 430 diaphragm type
Steering Engine			ZF technology
Cab			MAN F3000 mid-lengthened flat roof cabin with A/C and sleeper
Axle	Front		9.5 tons
	Rear		2*16 ton hub reduction axle, final ratio: 5.262
Tire			11.00R20 / 12.00R20 / 12R22.5 / 315 / 80R22.5 (10+1)
Fuel Tank (L)			300

Shaanxi Automobile Group is a leading exporter of self-discharging trucks in China. Shanqi has many years of F3000 6×4 dump truck production experience. Our products also cover off-road vehicles, medium-duty trucks, large and medium-sized coaches, medium and light-duty trucks, minivan, new energy vehicles, heavy-duty axles, light axles, Cummins engines, automobile parts, etc. Shacman dump trucks are sold to more than 80 countries including Eastern Europe and CIS countries, Africa, Southeast Asia, Central and South America, Middle East, and so on.
